TSX | DIN 89345 | EMC Strain Relief Cable Gland For all Types of Braided/Screened Cables

Please note the TSX range has been developed in accordance with DIN 89345 and must only be used in installations where this standard is followed.

The TSX range of strain relief metal cable glands are designed for superior EMC performance, whilst also utilising a armour clamping cone & ring design, and have a temperature rating of +105°C to -60°C.

The TSX range meets the requirements of well-known cable gland standards including EN 62444 and IEC 62444.

For more specific applications IP68 & IP69X ingress discs or plugs are available.

Features include:

  • Designed for superior EMC performance
  • Clamping cone and ring design
  • 360° contact round screen circumference
  • 3rd party EMC performance tested to EN 55032
  • Finger-locking seal provides superior cable retention and strain relief
  • 3rd party certified to IEC/EN 62444
  • Widest cable range take on the market
  • Robust design, high quality materials
  • O-ring interface seal included as standard
  • Transit disc or IP68, IP69 and IP69K rated IP plug options available
  • Product supplied in nickel-plated brass, or stainless steel on request
  • Ex eb certified product also available
  • Nickel-plated brass locknut available (ordering suffix 2TN)

Tightening tools may be required to aid installation. For further information, please click here.

Design Specification IEC 62444, EN 62444, DIN 89345 (EN Metric only)
Mechanical Classifications* Impact = Level 6, Cable Anchorage = Type A
Enclosure Protection IK08 to IEC 62262 (7 joules)
Ingress Protection Rating** IP66, IP67, IP68**, IP69 & IP69K
Cable Gland Material Nickel-plated brass, Stainless Steel (option)
Seal Material CMP SOLO LSF Halogen-free Thermoset Elastomer
Cable Type Braided
Sealing Technique CMP Unique finger-locking type seal
Sealing Area(s) Cable Outer Sheath
ECAS Certificate 24-03-106290/E24-03-110155/NB0007

* Mechanical classifications applied as per IEC/EN 62444
** IP68 tested to 300 kPa for 16 hours (equivalent to 30 metres water depth)

Jump to technical illustration

Click here to view how to order

Dual SealAvailable Entry Threads 'C'Overall Cable Diameter 'A'Cable Bedding Diameter 'F'Across Flats 'D'Across Corners 'D'Protrusion Length 'B'
Cable Gland OnlyCable Gland with LocknutMetricThread Length (Metric) 'E'Long Thread Length (Metric) 'E'NPTThread Length (NPT) 'E'MinMaxMaxMax
40DTSX1TA540DTSX2TN5M408.015.01 1⁄4”
50DTSX1TA550DTSX2TN5M509.015.01 1⁄2”
Standard SealAvailable Entry Threads 'C'Overall Cable Diameter 'A'Cable Bedding Diameter 'F'Across Flats 'D'Across Corners 'D'Protrusion Length 'B'
Cable Gland OnlyCable Gland with LocknutMetricThread Length (Metric) 'E'Long Thread Length (Metric) 'E'NPTThread Length (NPT) 'E'MinMaxMaxMax
40STSX1TA540STSX2TN5M408.015.01 1⁄4”
40TSX1TA540TSX2TN5M408.015.01 1⁄4”
50STSX1TA550STSX2TN5M509.015.01 1⁄2”
50TSX1TA550TSX2TN5M509.015.01 1⁄2”
For NPT threads add a ‘T’ to the suffix e.g. 16DTSX1TA5T (3⁄8” NPT)
For long metric threads add an ‘L’ to the suffix e.g. 16DTSX1TA5L (M16, with 12mm length of entry thread).
Dimensions are displayed in millimetres unless otherwise stated.

Technical Illustration

Additional Information

DIN 40050 Definitions

The following page provides an explanation of ingress protection codes according to DIN 40050-9 (liquids) and IEC 60529 (dusts).

Read more

Electrical Safety in the Work Place

Local codes of practice or regulations may be in force to ensure that safety is maintained to eliminate the possibility of accidents arising from the danger of electricity. These dangers would include electric shock, burns, fire, explosion and arcing. In the United Kingdom the ESQCR 2002, and amendments 2006 (S.I. No. 1521) and 2009 (S.I. No. 639), introduced under Statutory Instrument No. 2665, and the Electricity at Work Regulations 1989 (EAW Regulations), which came into force on 1 April 1990, comprehensively deal with this subject.

Read more

EMC Performance

Tests were carried out in an anechoic chamber using various CMP cable glands with a section of cable connected to it which would act as an aerial. A known electrical radiation source was used to introduce interference into the chamber, and the level of radiation in the cable shield was measured.

Read more
